Integrated bed makes concentricity, verticality, precision better

two linked right move claws，compatible with a variety of pipe without adjusting jaws, no need to adjust claw

clamping force optimization design avoids deformation

Innovative one-way air control claw tightness helps extend cylinder life

Visual scale adjustable support lifting device saves feeding time, ensures concentricity, prevents pipe swinging

integrated circuits, streamline laying provides easy maintenance and low failure rate

Automatic boundary

-Automatically find center

-Automatic compensation

-Adjustable frequency perforation

high damping bed, good rigidity, high speed and acceleration

Automatic bundle loader for option which saves labor and loading time, achieve mass production purpose

Round pipe, rectangular pipe and other pipes can be fully automated loading, without human intervention. Other shapes pipe can be semi-automatic feeding artificially.

 GENERAL DETAILS

Max Loading Bundle 800*800mm

Max Loading Bundle Weight 2500kg

The total feed manipulator with frame and strand width control transport links in 2200mm, total height control in 2300mm, maximum height of not more than 2500mm. So overall into containers

The tape support frame for easy removal

Feeding robot body with a chain conveyor link structure integrated design, easy to debug transport

AUTOMATIC COLLECTING

Automatic elevating support, receive tube and scrap into the basket

Visual scale support can adjust support diameter quickly according to pipe diameter

Visual scale adjustable support lifting device saves feeding time, ensures concentricity, prevents pipe swinging

The pneumatic system components used AirTAC or other more high-end brand, PLC control, sensors and other selected Omron, Schneider and other well-known brands. Ensure the stability of the system and export standard

The world’s leading fiber laser resonator and electronic components to ensure machine superior stability
